Dimensions (W x H x D) | 30.4 mm x 53 mm x 80 mm |
Sensing distance | 10 mm 1) |
Housing design (light emission) | Rectangular |
Light source | LED, green 2) |
Wave length | 520 nm |
Light emission | Long and short side of housing, exchangeable |
Light spot size | 1.2 mm x 4.2 mm |
Light spot direction | Vertical 3) |
Adjustment | Potentiometer |
Output function | Light/dark switching |
Supply voltage | 10 V DC … 30 V DC 1) |
Ripple | ≤ 5 Vpp 2) |
Power consumption | < 80 mA 3) |
Switching frequency | 10 kHz 4) |
Response time | 50 µs 5) |
Switching output | PNP |
Switching output (voltage) | PNP: HIGH = VS– ≤ 2 V / LOW approx. 0 V |
Switching output | Light/dark switching |
Analog output | 0.3 mA … 10 mA |
Output current Imax. | 100 mA 6) |
Connection type | Male connector M12, 4-pin |
Protection class | II 7) |
Circuit protection | UV connections, reverse polarity protected
Output Q short-circuit protected Interference pulse suppression |
Enclosure rating | IP67 |
Weight | 400 g |
Housing material | Metal, Zinc diecast |
