Dimensions (W x H x D) | 12 mm x 31.5 mm x 21 mm |
Sensing distance | 12.5 mm |
Sensing distance tolerance | ± 3 mm |
Housing design (light emission) | Rectangular |
Light source | LED, RGB 1) |
Wave length | 470 nm, 525 nm, 625 nm |
Light emission | Long side of housing |
Light spot size | 1.5 mm x 6.5 mm |
Light spot direction | Vertical 2) |
Receiving filters | None |
Adjustment | Teach-in button |
Teach-in mode | 2-point teach-in static/dynamic + proximity to mark
ET: Teach-in dynamic |
Supply voltage | 12 V DC … 24 V DC 1) |
Ripple | ≤ 5 Vpp 2) |
Power consumption | < 50 mA 3) |
Switching frequency | 15 kHz 4) |
Response time | 32 µs 5) |
Jitter | 15 µs |
Switching output | PNP |
Switching output (voltage) | PNP: HIGH = VS– ≤ 2 V / LOW approx. 0 V |
Switching output | Light/dark switching |
Output current Imax. | 50 mA 6) |
Input, dynamic teach-in (ET) | PNP: Teach: U = 10,8 V … < UV
PNP: Run: U < 2 V or open |
Retention time (ET) | 28 ms, non-volatile memory |
Time delay | None |
Connection type | Male connector M8, 4-pin |
Protection class | III |
Circuit protection | UV connections, reverse polarity protected
Output Q short-circuit protected Interference pulse suppression |
Enclosure rating | IP67 |
Weight | 20 g |
Housing material | Plastic, ABS |
Optics material | Plastic, PMMA |
