Supply voltage Vs | DC 10 V … 30 V 1) |
Ripple | ≤ 5 Vpp 2) |
Power consumption | ≤ 1.85 W 3) |
Initialization time | ≤ 350 ms |
Warm-up time | ≤ 15 min |
Housing material | Metal (Zinc diecast) |
Window material | Plastic (PMMA) |
Connection type | Male connector, M12, 5-pin |
Indication | LC display, 2 x LED |
Weight | 200 g |
Dimensions (W x H x D) | 36.1 mm x 62.7 mm x 57.7 mm |
Enclosure rating | IP65 |
Protection class | III |
Measuring range | 200 mm … 10,000 mm, 90 % remission
200 mm … 6,000 mm, 18 % remission 200 mm … 4,000 mm, 6 % remission |
Target | Natural objects |
Resolution | 1 mm 1) |
Repeatability | ≥ 2.5 mm 2) 3) 4) |
Accuracy | ± 10 mm 1) 5) |
Response time | 10 ms … 50 ms, 10 ms / 50 ms 4) |
Switching frequency | 50 Hz / 10 Hz 4) |
Light source | Laser, red visible red light |
Laser class | 2 (IEC 60825-1:2014, EN 60825-1:2014) 6) |
Typ. light spot size (distance) | 15 mm x 15 mm (10 m) |
Additional function | Set moving average: fast/slow, adjustable operating modes: Switching point (DtO) / Switching window/Background (ObSB), teach-in, scaling and inversion of digital output, set hysteresis, Multifunctional input: laser off / external teach / deactivated, Unique measurement value, crosstalk safety, switch-off display, reset to factory default, lock user interface |
