Device type | Fibers |
Detection principle | Proximity system |
For fiber-optic sensor | GLL170(T), WLL180T |
Fiber length | 500 mm |
Fiber material | Polymethylmethacrylat (PMMA) |
Jacket material | Polyethylen (PE) |
Fiber head material | Stainless steel 1) |
Outer diameter, fiber-optic cable connection | 1 mm |
Fiber-optic cable cuttable | ✔ 2) |
Thread size | M3 |
Fiber-optic head design | Threaded sleeve, Long end sleeve |
Fiber arrangement | Monofiber |
Core structure | 2 x Ø 0,25 mm 3) Monofiber |
Bend radius, fibre-optic cable | 4 mm |
Angle of dispersion < 60° | No |
Compatibility with infrared light (1,450 nm) | No |
Ambient operating temperature | –40 °C … +70 °C |
Application | High flexible (static), Robotics (dynamic flexible) |
Diameter/thread size from 2 mm taper | ≥ 0.82 mm |
Length of taper | ≥ 15 mm |
Diameter of taper | ≥ 0.82 mm |
Highly flexible/elastic fibers (bend radius 1–4 mm) | Yes |
Adapter end sleeves required | Yes |
Angle of dispersion | 60° |
Integrated lens | No |
Minimal object diameter | 0.015 mm 4) |
Included with delivery | Mounting, 2 x M3 hexagon nut, 2 x washer, adapter sleeves, BF-WLL160-10 (1.0 mm) adapter sleeves, FC fiber cutter (5304141) |
Compatibility tip adapters | No |
Special features | Compact, thin tip |
