Housing | Cylindrical thread design |
Thread size | M30 x 1.5 |
Diameter | Ø 30 mm |
Sensing range Sn | 20 mm |
Safe sensing range Sa | 16.2 mm |
Installation type | Flush |
Switching frequency | 100 Hz |
Connection type | Male connector M12, 4-pin |
Switching output | NPN |
Output function | NO |
Electrical wiring | DC 3-wire |
Enclosure rating | IP68, IP69K 1) |
Special features | Sensing face made of stainless steel V4A, Resistant to cleaning agents, triple sensing range, Visual adjustment indicator |
Special applications | Hygienic and washdown zones, Difficult application conditions |
Supply voltage | 10 V DC … 30 V DC |
Ripple | ≤ 20 % 1) |
Voltage drop | ≤ 2 V 2) |
Current consumption | 10 mA 3) |
Time delay before availability | ≤ 40 ms |
Hysteresis | 1 % … 15 % |
Reproducibility | ≤ 5 % 4) 5) |
Temperature drift (of Sr) | ≤ 10 % |
EMC | According to EN 60947-5-2 |
Continuous current Ia | ≤ 200 mA |
Short-circuit protection | ✔ |
Reverse polarity protection | ✔ |
Power-up pulse protection | ✔ |
Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
Ambient operating temperature | –25 °C … +85 °C |
Housing material | Stainless steel V4A, DIN 1.4404 / AISI 316L |
Sensing face material | Stainless steel V4A, DIN 1.4404 / AISI 316L |
Housing length | 63.5 mm |
Thread length | 42 mm |
Tightening torque, max. | ≤ 150 Nm |
Items supplied | Mounting nut, V4A stainless steel (2x)
Washer, V4A stainless steel, with locking teeth (2x) |
Protection class | III |
UL File No. | E191603 |
