Sensor/ detection principle | Through-beam photoelectric sensor |
Dimensions (W x H x D) | 7.7 mm x 21.8 mm x 13.5 mm |
Housing design (light emission) | Rectangular |
Sensing range max. | 0 m … 3 m |
Sensing range | 0 m … 2 m |
Adjustment | None |
Supply voltage | 10 V DC … 30 V DC 1) |
Ripple | ≤ 5 Vpp 2) |
Current consumption | 20 mA 3) |
Switching output | PNP |
Switching mode | Light switching |
Output current Imax. | < 50 mA |
Response time | < 0.6 ms 4) |
Switching frequency | 800 Hz 5) |
Connection type | Cable, 3-wire, 2 m 6) |
Cable material | PVC |
Cable diameter | Ø 3 mm |
Circuit protection | A 7)
C 8) D 9) |
Weight | 33.7 g |
Housing material | Plastic, ABS |
Optics material | Plastic, PMMA |
Enclosure rating | IP67 |
Special feature | Receiver |
Ambient operating temperature | –25 °C … +50 °C |
Ambient storage temperature | –40 °C … +75 °C |
UL File No. | NRKH.E181493 |
