LOGO!8 Analog Modules | LOGO! AM2 | LOGO! AM2 RTD | LOGO! AM2 AQ |
Supply voltage | 12 V…24 V DC | 12 V…24 V DC | 24 V DC |
Permitted range | 10.8 V… 28.8 V DC | 10.8 V… 28.8 V DC | 20.4 V… 28.8 V DC |
Analog inputs / analog outputs | 2 / 0 | 2 / 0
2 x PT100 or PT1000 2-wire or 3-wire |
0 / 2 |
Measuring range | – | -50 °C … +200 °C | – |
Input range | 0 … 10 V or 0/4 … 20 mA | – | – |
Output range | – | – | 0 … 10 V or 0/4 … 20 mA |
Resolution | 10 bit
standardized to 0–1000 |
0.25 °C | 10 bit
standardized to 0–1000 |
Cable length (shielded and twisted) | max. 10 m | max. 10 m | max. 10 m |
Encoder supply | none | 0.5 mA | – |
Power loss at 12 V DC at 24 V DC |
0.2 W to 0.4 W 0.4 W to 0.8 W |
0.2 W to 0.4 W 0.4 W to 0.8 W |
– 0.4 W to 2.0 W |
Dimensions (W x H x D) | 35.5 (2 MW) x 90 x 58 mm | 35.5 (2 MW) x 90 x 58 mm | 35.5 (2 MW) x 90 x 58 mm |
