| LOGO! 8 digital modules | LOGO! DM8 12/24R | LOGO! DM8 24 / LOGO! DM16 24 | LOGO! DM8 24R / LOGO! DM16 24R | LOGO! DM8 230R / LOGO! DM16 230R |
| Inputs | 4 | 4 / 8 | 4 / 8 | 4 / 8 |
| Input / supply voltage | 12…24 V DC | 24 V DC | 24 V AC/DC* /
24 V DC** |
115…230 V AC/DC |
| Permitted range | 10.8 V… 28.8 V DC | 20.4…. 28.8 V DC | 20.4 V AC to 26.4 V AC*
20.4 V DC to 28.8 V DC |
85 V AC to 265 V AC
100 V DC to 253 V DC |
| with signal “0”
with signal “1” |
max. 5 V DC min. 8.5 V DC | max. 5 V DC min. 12 V DC | max. 5 V AC*/DC*/** min. 12 V AC*/DC*/** | max. 40 V AC min. 79 V AC |
| Input current | 1.5 mA | 2.1 mA* / 2 mA** | 2.63 mA* / 2 mA** | 0.08 mA AC
0.13 mA DC |
| Outputs | 4; relays | 4 / 8; transistors | 4 / 8; relays | 4 / 8; relays |
| Continuous current | 5 A with resistive load; 3 A with inductive load | 0.3 A | 5 A with resistive load; 3 A with inductive load | 5 A with resistive load; 3 A with inductive load |
| Short-circuit protection | External fuse required | Electronic (approx. 1 A) | External fuse required | External fuse required |
| Switching frequency | 2 Hz with resistive load;
0.5 Hz with inductive load |
10 Hz | 2 Hz with resistive load;
0.5 Hz with inductive load |
2 Hz with resistive load;
0.5 Hz with inductive load |
| Power loss | 0.2 1.0 W at 12 V DC
0.3 1.0 W at 24 V DC |
0.4….. 1.0 W*
0.4….. 1.5 W* |
0.5…. 2.4 W at 24 V AC*
0.2…. 1.2 W at 24 V DC* 0.35….. 1.6 W at 24 V DC** |
1.1. 3.3 W at 115 V AC*
2.4. 4.8 W at 240 V AC* 0.5. 1.8 W at 115 V DC* 1.2. 2.4 W at 240 V DC* 1.1. 4.5 W at 115 V AC** 2.4. 5.5 W at 240 V AC** 0.6. 2.9 W at 115 V DC** 1.2. 4.8 W at 240 V DC** |
| Dimensions (W x H x D) | 35.5 (2 MW) x 90 x 58 mm | 35.5 (2 MW)* x 90 x
58 mm / 71.5 (4 MW)* x 90 x 60 mm |
35.5 (2 MW)* x 90 x
58 mm / 71.5 (4 MW)** x 90 x 60 mm |
35.5 (2 MW)* x 90 x
58 mm / 71.5 (4 MW)** x 90 x 60 mm |
