Article number | 6GK7242-5DX30-0XE0 |
Product type designation | CM 1242-5 |
Transfer rate | |
Transfer rate | |
● at the 1st interface acc. to PROFIBUS | 9.6 kbit/s … 12 Mbit/s |
Interfaces | |
Number of interfaces acc. to Industrial Ethernet | 0 |
Number of electrical connections | |
● at the 1st interface acc. to PROFIBUS | 1 |
● for power supply | 0 |
Type of electrical connection | |
● at the 1st interface acc. to PROFIBUS | 9-pin Sub-D socket (RS485) |
Supply voltage, current consumption, power loss | |
Type of voltage of the supply voltage | DC |
Supply voltage 1 from backplane bus | 5 V |
Consumed current | |
● from backplane bus at DC at 5 V typical | 0.15 A |
Power loss [W] | 0.75 W |
Ambient conditions | |
Ambient temperature | |
● for vertical installation during operation | 0 … 45 °C |
● for horizontally arranged busbars during operation | 0 … 55 °C |
● during storage | -40 … +70 °C |
● during transport | -40 … +70 °C |
Relative humidity | |
● at 25 °C without condensation during operation maximum | 95 % |
Protection class IP | IP20 |
Design, dimensions and weights | |
Module format | Compact module S7-1200 single width |
Width | 30 mm |
Height | 100 mm |
Depth | 75 mm |
Net weight | 0.115 kg |
Mounting type | |
● 35 mm DIN rail mounting | Yes |
● S7-300 rail mounting | No |
● wall mounting | Yes |
Product features, product functions, product components general | |
Number of units | |
● per CPU maximum | 3 |
Performance data PROFIBUS DP | |
Service as DP slave | |
● DPV0 | Yes |
● DPV1 | Yes |
Amount of data | |
● of the address area of the inputs as DP slave total | 240 byte |
● of the address area of the outputs as DP slave total | 240 byte |
Performance data telecontrol | |
Protocol is supported | |
● TCP/IP | No |
Product functions management, configuration, engineering | |
Configuration software | |
● required | STEP 7 Basic/Professional |
