Siemens PLCs Communication module CM 1243-5 6GK7243-5DX30-0XE0

Series#: Siemens PLC

Product Details

PROFIBUS DPV1 master in accordance with IEC 61158
Support of up to 16 PROFIBUS DP slaves
Communication with other S7 controllers based on S7 communication
Allows programming devices and operator panels with PROFIBUS interfaces to be connected to the SIMATIC S7-1200
Module replacement without PG supported
Support of all standard baud rates from 9.6 kbps to 12 Mbps
Compact industrial enclosure in SIMATIC S7-1200 design for mounting on a DIN rail
Fast commissioning thanks to easy configuration using STEP 7 without additional programming overhead

Qty:

Add to Enquiry Cart

Article number	6GK7243-5DX30-0XE0
Transfer rate
Transfer rate
● at the 1st interface acc. to PROFIBUS	9.6 kbit/s … 12 Mbit/s
Interfaces
Number of interfaces acc. to Industrial Ethernet	0
Number of electrical connections
● at the 1st interface acc. to PROFIBUS	1
● for power supply	1
Type of electrical connection
● at the 1st interface acc. to PROFIBUS	9-pin Sub-D socket (RS485)
● for power supply	3-pole terminal block
Supply voltage, current consumption, power loss
Type of voltage of the supply voltage	DC
Supply voltage external	24 V
Supply voltage external at DC Rated value	24 V
Relative positive tolerance at DC at 24 V	20 %
Relative negative tolerance at DC at 24 V	20 %
Consumed current
● from external supply voltage at DC at 24 V typical	0.1 A
Power loss [W]	2.4 W
Ambient conditions
Ambient temperature
● for vertical installation during operation	0 … 45 °C
● for horizontally arranged busbars during operation	0 … 55 °C
● during storage	-40 … +70 °C
● during transport	-40 … +70 °C
Relative humidity
● at 25 °C without condensation during operation maximum	95 %
Protection class IP	IP20
Design, dimensions and weights
Module format	Compact module S7-1200 single width
Width	30 mm
Height	100 mm
Depth	75 mm
Net weight	0.134 kg
Mounting type
● 35 mm DIN rail mounting	Yes
● S7-300 rail mounting	No
● wall mounting	Yes
Product features, product functions, product components general
Number of units
● per CPU maximum	3
Performance data PROFIBUS DP
Service as DP master
● DPV1	Yes
Number of DP slaves
● on DP master usable	32
Amount of data
● of the address area of the inputs as DP master total	512 byte
● of the address area of the outputs as DP master total	512 byte
● of the address area of the inputs per DP slave	244 byte
● of the address area of the outputs per DP slave	244 byte
● of the address area of the diagnostic data per DP slave	240 byte
Service as DP slave
● DPV0	No
● DPV1	No
Performance data S7 communication
Number of possible connections for S7 communication
● maximum	8; max. 4 connections to other S7 stations
● with PG connections maximum	1
● with PG/OP connections maximum	3
Performance data multi-protocol mode
Number of active connections with multi-protocol mode
● without DP maximum	8
● with DP maximum	8
Performance data telecontrol
Protocol is supported
● TCP/IP	No
Product functions management, configuration, engineering
Configuration software
● required	STEP 7 Basic/Professional

Article number

6GK7243-5DX30-0XE0

Product type designation

CM 1243-5

Transfer rate

Transfer rate

● at the 1st interface acc. to PROFIBUS

9.6 kbit/s … 12 Mbit/s

Interfaces

Number of interfaces acc. to Industrial Ethernet

Number of electrical connections

● at the 1st interface acc. to PROFIBUS

● for power supply

Type of electrical connection

● at the 1st interface acc. to PROFIBUS

9-pin Sub-D socket (RS485)

● for power supply

3-pole terminal block

Supply voltage, current consumption, power loss

Type of voltage of the supply voltage

Supply voltage external

24 V

Supply voltage external at DC Rated value

24 V

Relative positive tolerance at DC at 24 V

20 %

Relative negative tolerance at DC at 24 V

20 %

Consumed current

● from external supply voltage at DC at 24 V typical

0.1 A

Power loss [W]

2.4 W

Ambient conditions

Ambient temperature

● for vertical installation during operation

0 … 45 °C

● for horizontally arranged busbars during operation

0 … 55 °C

● during storage

-40 … +70 °C

● during transport

-40 … +70 °C

Relative humidity

● at 25 °C without condensation during operation maximum

95 %

Protection class IP

IP20

Design, dimensions and weights

Module format

Compact module S7-1200 single width

Width

30 mm

Height

100 mm

Depth

75 mm

Net weight

0.134 kg

Mounting type

● 35 mm DIN rail mounting

Yes

● S7-300 rail mounting

● wall mounting

Yes

Product features, product functions, product components general

Number of units

● per CPU maximum

Performance data PROFIBUS DP

Service as DP master

● DPV1

Yes

Number of DP slaves

● on DP master usable

Amount of data

● of the address area of the inputs as DP master total

512 byte

● of the address area of the outputs as DP master total

512 byte

● of the address area of the inputs per DP slave

244 byte

● of the address area of the outputs per DP slave

244 byte

● of the address area of the diagnostic data per DP slave

240 byte

Service as DP slave

● DPV0

● DPV1

Performance data S7 communication

Number of possible connections for S7 communication

● maximum

8; max. 4 connections to other S7 stations

● with PG connections maximum

● with PG/OP connections maximum

Performance data multi-protocol mode

Number of active connections with multi-protocol mode

● without DP maximum

● with DP maximum

Performance data telecontrol

Protocol is supported

● TCP/IP

Product functions management, configuration, engineering

Configuration software

● required

STEP 7 Basic/Professional
