| Article number | 6GK5875-0AA10-1AA2 |
| Product type designation | SCALANCE M875 UMTS ROUTER |
| Transmission rate | |
| Transfer rate | 10 Mbit/s, 100 Mbit/s |
| Transfer rate | |
|
● for GSM transmission
|
9 600 bit/s |
|
● for GPRS transmission with downlink maximum
|
85.6 kbit/s |
|
● for GPRS transmission with uplink maximum
|
42.8 kbit/s |
|
● with eGPRS transmission with downlink maximum
|
236.8 kbit/s |
|
● with eGPRS transmission with uplink maximum
|
118 kbit/s |
|
● with UMTS transmission with downlink maximum
|
14.4 Mbit/s |
|
● with UMTS transmission with uplink maximum
|
5.76 Mbit/s |
| Interfaces | |
| Number of electrical connections | |
|
● for internal network
|
2 |
|
● for external network
|
2 |
| Number of electrical connections | |
|
● for power supply
|
1 |
| Type of electrical connection | |
|
● for internal network
|
RJ45 port (10/100 Mbit/s, TP, autocrossover) |
|
● for external network
|
SMA antenna socket (50 ohms) |
|
● for power supply
|
Terminal strip |
| WAN connection | |
| Type of mobile network is supported | GSM, UMTS |
| Type of mobile wireless service is supported | GPRS, eGPRS, HSPA+ |
| Operating frequency for GSM transmission | 850 MHz, 900 MHz, 1800 MHz, 1900 MHz |
| Operating frequency with UMTS transmission | 800 MHz, 850 MHz, 900 MHz, 1900 MHz, 2100 MHz |
| Supply voltage, current consumption, power loss | |
| Supply voltage Rated value | 24 V |
| Supply voltage rated value | 12 … 30 |
| Type of voltage of the supply voltage | DC |
| Consumed current at rated supply voltage maximum | 450 mA |
| Power loss [W] | |
|
● typical
|
4 W |
| Permitted ambient conditions | |
| Ambient temperature | |
|
● during operation
|
-40 … +75 °C |
|
● during storage
|
-40 … +85 °C |
| Relative humidity at 25 °C during operation maximum | 95 % |
| Protection class IP | IP20 |
| Design, dimensions and weight | |
| Design | compact |
| Depth | 114 mm |
| Width | 45 mm |
| Net weight | 280 g |
| Mounting type | |
|
● 35 mm DIN rail mounting
|
Yes |
|
● S7-300 rail mounting
|
No |
|
● S7-1500 rail mounting
|
No |
|
● wall mounting
|
No |
| Product properties, functions, components general | |
| Product function | |
|
● DynDNS-Client
|
Yes |
| Product functions management, configuration | |
| Product function | |
|
● CLI
|
No |
|
● web-based management
|
Yes |
|
● MIB support
|
No |
|
● TRAPs via email
|
No |
| Protocol is supported | |
|
● Telnet
|
No |
|
● HTTP
|
No |
|
● HTTPS
|
Yes |
| Type of configuration | Web-based management |
| Product functions Diagnosis | |
| Product function | |
|
● Statistics Packet Size
|
No |
|
● Statistics packet type
|
No |
|
● Error statistics
|
No |
|
● SysLog
|
Yes |
|
● Packet Filter Log
|
Yes |
| Product functions DHCP | |
| Product function | |
|
● DHCP client
|
Yes |
|
● DHCP server – internal network
|
Yes |
| Product functions Routing | |
| Router function | |
|
● NAT (IP masquerading)
|
Yes |
|
● Port forwarding
|
Yes |
|
● NAT traversal
|
Yes |
|
● 1:1 NAT
|
Yes |
|
● DNS cache
|
Yes |
| Product functions Security | |
| Suitability for operation Virtual Private Network | Yes |
| Firewall version | Statefull Inspection |
| Product function | |
|
● Password protection
|
Yes |
|
● packet filter
|
Yes |
|
● Broadcast/Multicast/Unicast Limiter
|
No |
| Product function | |
|
● broadcast blocking
|
No |
|
● with VPN connection
|
IPSec |
| Number of possible connections with VPN connection | 10 |
| Type of authentication with Virtual Private Network PSK | Yes |
| Protocol is supported | |
|
● IPsec tunnel and transport mode
|
Yes |
| Key length | |
|
● with IPsec DES with Virtual Private Network
|
56 bit |
|
● 1 with IPsec AES with Virtual Private Network
|
128 bit |
|
● 2 with IPsec AES with Virtual Private Network
|
192 bit |
|
● 3 with IPsec AES with Virtual Private Network
|
256 bit |
|
● with IPsec 3DES with Virtual Private Network
|
168 bit |
| Type of Internet key exchange with Virtual Private Network | |
|
● main mode
|
Yes |
|
● quick mode
|
Yes |
| Type of packet authentication with Virtual Private Network | MD5, SHA-1 |
| IETF profile with Virtual Private Network X.509v3 certificate | Yes |
| Product functions Time | |
| Protocol is supported | |
|
● NTP
|
Yes |
| Standards, specifications, approvals | |
| Standard | |
|
● for safety from CSA and UL
|
yes |
|
● for emitted interference
|
EN55022 Class A |
|
● for interference immunity
|
EN 61000-6-2 |
| Certificate of suitability | EN 61000-6-2 |
|
● CE marking
|
Yes |
|
● E1 approval
|
No |
|
● E1 approval
|
No |
|
● Railway application in accordance with EN 50121-3-2
|
Yes |
|
● Railway application in accordance with EN 50155
|
Yes; no coated printed circuit boards |
|
● railway application in accordance with EN 61373
|
Yes; cat. 1, cl. B |
