| Article number | 6GK5005-0BA10-1AA3 | 6GK5005-0BA10-1CA3 |
| Product type designation | SCALANCE X005 | SCALANCE X005EEC |
| Transfer rate | ||
| Transfer rate | 10 Mbit/s, 100 Mbit/s | 10 Mbit/s, 100 Mbit/s |
| Interfaces for communication Integrated | ||
| Number of electrical connections | ||
|
● for network components or terminal equipment
|
5; RJ45 with securing collar | 5; RJ45 with securing collar |
| Number of 100 Mbit/s SC ports | ||
|
● for multimode
|
0 | 0 |
| Interfaces other | ||
| Number of electrical connections | ||
|
● for power supply
|
1 | 1 |
| Type of electrical connection | ||
|
● for power supply
|
2-pole terminal block | 2-pole terminal block |
| Supply voltage, current consumption, power loss | ||
| Type of voltage of the supply voltage | DC | DC |
| Supply voltage | ||
|
● external
|
24 V | 24 V |
|
● external minimum
|
18 V | 18 V |
|
● external maximum
|
32 V | 32 V |
| Product component fusing at power supply input | Yes | Yes |
| Fuse protection type at input for supply voltage | 0.5 A / 60 V | 0.5 A / 60 V |
| Consumed current maximum | 0.08 A | 0.08 A |
| Power loss [W] | ||
|
● at DC at 24 V
|
2 W | 2 W |
| Ambient conditions | ||
| Ambient temperature | ||
|
● during operation
|
-40 … +75 °C | -40 … +75 °C |
|
● during storage
|
-40 … +80 °C | -40 … +80 °C |
|
● during transport
|
-40 … +80 °C | -40 … +80 °C |
| Relative humidity | ||
|
● at 25 °C without condensation during operation maximum
|
95 % | 95 % |
| Protection class IP | IP30 | IP30 |
| Design, dimensions and weights | ||
| Design | compact | compact |
| Width | 40 mm | 40 mm |
| Height | 125 mm | 125 mm |
| Depth | 124 mm | 124 mm |
| Net weight | 0.55 kg | 0.55 kg |
| Product feature conformal coating | No | |
| Mounting type | ||
|
● 35 mm DIN rail mounting
|
Yes | Yes |
|
● wall mounting
|
Yes | Yes |
|
● S7-300 rail mounting
|
Yes | Yes |
|
● S7-1500 rail mounting
|
No | No |
| Product functions management, configuration, engineering | ||
| Product function | ||
|
● multiport mirroring
|
No | No |
|
● CoS
|
Yes | Yes |
| Product function switch-managed | No | No |
| Product functions redundancy | ||
| Product function | ||
|
● Parallel Redundancy Protocol (PRP)/operation in the PRP-network
|
Yes | Yes |
|
● Parallel Redundancy Protocol (PRP)/Redundant Network Access (RNA)
|
No | No |
| Standards, specifications, approvals | ||
| Standard | ||
|
● for safety from CSA and UL
|
UL 60950-1, CSA C22.2 No. 60950-1 | UL 60950-1, CSA C22.2 No. 60950-1 |
|
● for emitted interference
|
EN 61000-6-4 (Class A) | EN 61000-6-4 (Class A) |
|
● for interference immunity
|
EN 61000-6-2 | EN 61000-6-2 |
| MTBF | 167.1 y | 165 y |
| Standards, specifications, approvals CE | ||
| Certificate of suitability CE marking | Yes | Yes |
