| Article number |
6GK5204-2BB10-2AA3 |
6GK5204-2BB11-2AA3 |
6GK5204-2BB10-2CA2 |
| Product type designation |
SCALANCE X204-2 |
SCALANCE X204-2FM |
SCALANCE X204-2TS |
| Transfer rate |
|
|
|
| Transfer rate |
10 Mbit/s, 100 Mbit/s |
10 Mbit/s, 100 Mbit/s |
10 Mbit/s, 100 Mbit/s |
| Interfaces for communication Integrated |
|
|
|
| Number of electrical connections |
|
|
|
| ● for network components or terminal equipment |
4 |
4 |
4 |
| Number of 10/100 Mbit/s RJ45 ports Integrated |
|
|
|
| ● with securing collar |
4 |
4 |
4 |
| Number of 100 Mbit/s ST(BFOC) ports |
|
|
|
| ● for multimode |
2 |
2 |
2 |
| Interfaces other |
|
|
|
| Number of electrical connections |
|
|
|
| ● for signaling contact |
1 |
1 |
1 |
| ● for power supply |
1 |
1 |
1 |
| ● for redundant voltage supply |
1 |
1 |
1 |
| Type of electrical connection |
|
|
|
| ● for signaling contact |
2-pole terminal block |
2-pole terminal block |
2-pole terminal block |
| ● for power supply |
4-pole terminal block |
4-pole terminal block |
4-pole terminal block |
| design of the removable storage |
|
|
|
| ● C-PLUG |
Yes |
Yes |
Yes |
| Signal inputs/outputs |
|
|
|
| Operating voltage of the signaling contacts |
|
|
|
| ● at DC Rated value |
24 V |
24 V |
24 V |
| Operating current of the signaling contacts |
|
|
|
| ● at DC maximum |
0.1 A |
0.1 A |
0.05 A |
| Supply voltage, current consumption, power loss |
|
|
|
| Type of voltage of the supply voltage |
DC |
DC |
DC |
| Supply voltage |
|
|
|
| ● external |
24 V |
24 V |
12 V |
| ● external minimum |
18 V |
18 V |
10 V |
| ● external maximum |
32 V |
32 V |
30 V |
| Supply voltage at DC |
|
|
24 V |
| ● rated value |
|
|
10 … 30 V |
| Product component fusing at power supply input |
Yes |
Yes |
Yes |
| Fuse protection type at input for supply voltage |
0.6 A / 60 V |
0.6 A / 60 V |
3 A / 32 V |
| Consumed current maximum |
0.265 A |
0.265 A |
0.6 A |
| Power loss [W] |
|
|
|
| ● at DC at 24 V |
6.36 W |
6.36 W |
6.6 W |
| Ambient conditions |
|
|
|
| Ambient temperature |
|
|
|
| ● during operation |
-40 … +60 °C |
-40 … +60 °C |
-40 … +70 °C |
| ● during storage |
-40 … +70 °C |
-40 … +70 °C |
-40 … +70 °C |
| ● during transport |
-40 … +70 °C |
-40 … +70 °C |
-40 … +70 °C |
| ● Note |
|
|
If the IE switch X-204-2TS is installed horizontally, a maximum ambient temperature of +40 °C is permitted |
| Relative humidity |
|
|
|
| ● at 25 °C without condensation during operation maximum |
95 % |
95 % |
95 % |
| Protection class IP |
IP30 |
IP30 |
IP20 |
