| Article number | 6GK5206-1BB10-2AA3 | 6GK5206-1BC10-2AA3 | 6GK5208-0BA10-2AA3 | 6GK5208-0HA10-2AA6 |
| Product type designation | SCALANCE X206-1 | SCALANCE X206-1LD | SCALANCE X208 | SCALANCE X208PRO |
| Transfer rate | ||||
| Transfer rate | 10 Mbit/s, 100 Mbit/s | 10 Mbit/s, 100 Mbit/s | 10 Mbit/s, 100 Mbit/s | 10 Mbit/s, 100 Mbit/s |
| Interfaces for communication Integrated | ||||
| Number of electrical connections | ||||
|
● for network components or terminal equipment
|
6 | 6 | 8 | 8 |
| Number of 10/100 Mbit/s RJ45 ports Integrated | ||||
|
● with securing collar
|
6 | 8 | ||
| Number of 10/100 Mbit/s M12-ports (D-coded) Integrated | 8 | |||
| Number of 100 Mbit/s ST(BFOC) ports | ||||
|
● for multimode
|
1 | |||
|
● for single mode (LD)
|
1 | |||
| Interfaces other | ||||
| Number of electrical connections | ||||
|
● for signaling contact
|
1 | 1 | 1 | 1 |
|
● for power supply
|
1 | 1 | 1 | 1 |
|
● for redundant voltage supply
|
1 | 1 | 1 | 1 |
| Type of electrical connection | ||||
|
● for signaling contact
|
2-pole terminal block | 2-pole terminal block | 2-pole terminal block | 5-pin M12 socket (b-coded) |
|
● for power supply
|
4-pole terminal block | 4-pole terminal block | 4-pole terminal block | 4-pin M12 interface (A-coded) |
| design of the removable storage | ||||
|
● C-PLUG
|
Yes | Yes | Yes | Yes |
| Signal inputs/outputs | ||||
| Operating voltage of the signaling contacts | ||||
|
● at DC Rated value
|
24 V | 24 V | 24 V | 24 V |
| Operating current of the signaling contacts | ||||
|
● at DC maximum
|
0.1 A | 0.1 A | 0.1 A | 0.1 A |
| Supply voltage, current consumption, power loss | ||||
| Type of voltage of the supply voltage | DC | DC | DC | DC |
| Supply voltage | ||||
|
● external
|
24 V | 24 V | 24 V | 24 V |
|
● external minimum
|
18 V | 18 V | 18 V | 18 V |
|
● external maximum
|
32 V | 32 V | 32 V | 32 V |
| Product component fusing at power supply input | Yes | Yes | Yes | Yes |
| Fuse protection type at input for supply voltage | 0.6 A / 60 V | 0.6 A / 60 V | 0.6 A / 60 V | 0.6 A / 60 V |
| Consumed current maximum | 0.22 A | 0.2 A | 0.185 A | 0.185 A |
| Power loss [W] | ||||
|
● at DC at 24 V
|
5.28 W | 5.28 W | 3.84 W | 4.4 W |
| Ambient conditions | ||||
| Ambient temperature | ||||
|
● during operation
|
-40 … +60 °C | -40 … +60 °C | -40 … +60 °C | -40 … +70 °C |
|
● during storage
|
-40 … +70 °C | -40 … +70 °C | -40 … +70 °C | -40 … +70 °C |
|
● during transport
|
-40 … +70 °C | -40 … +70 °C | -40 … +70 °C | -40 … +70 °C |
| Relative humidity | ||||
|
● at 25 °C without condensation during operation maximum
|
95 % | 95 % | 95 % | 95 % |
| Protection class IP | IP30 | IP30 | IP30 | IP65/67 |
