Article number | 6ES7131-6BF01-0AA0 | 6ES7131-6BF61-0AA0 | 6ES7131-6BF01-0BA0 | 6ES7131-6BH01-0BA0 |
ET 200SP, DI 8x 24V DC Basic, PU 1 | ET 200SP, DI 8x 24V DC SRC BA | ET 200SP, DI 8x 24V DC ST, PU 1 | ET 200SP, DI 16x 24V DC ST, PU 1 | |
General information | ||||
Product type designation | DI 8x24VDC BA | DI 8×24 VDC SRC BA | DI 8×24 VDC ST | DI 16x24VDC ST |
HW functional status | FS03 | From FS02 | From FS02 | From FS02 |
Firmware version | V0.0 | V0.0 | V0.0 | V0.0 |
● FW update possible
|
No | No | No | No |
usable BaseUnits | BU type A0 | BU type A0 | BU type A0 | BU type A0 |
Color code for module-specific color identification plate | CC01 | CC02 | CC01 | CC00 |
Product function | ||||
● I&M data
|
Yes; I&M0 to I&M3 | Yes; I&M0 to I&M3 | Yes; I&M0 to I&M3 | Yes; I&M0 to I&M3 |
● Isochronous mode
|
No | No | No | No |
Engineering with | ||||
● STEP 7 TIA Portal configurable/integrated from version
|
V14 | V14 | V14 | V14 |
● STEP 7 configurable/integrated from version
|
V5.5 SP3 / – | V5.5 SP3 / – | V5.5 SP3 or higher | V5.5 SP3 |
● PCS 7 configurable/integrated from version
|
V8.1 SP1 | V8.1 SP1 | ||
● PROFIBUS from GSD version/GSD revision
|
One GSD file each, Revision 3 and 5 and higher | One GSD file each, Revision 3 and 5 and higher | One GSD file each, Revision 3 and 5 and higher | One GSD file each, Revision 3 and 5 and higher |
● PROFINET from GSD version/GSD revision
|
GSDML V2.3 | GSDML V2.3 | GSDML V2.3 | GSDML V2.3 |
Operating mode | ||||
● DI
|
Yes | Yes | Yes | Yes |
● Counter
|
No | No | No | No |
● Oversampling
|
No | No | No | No |
● MSI
|
No | No | No | No |
Supply voltage | ||||
Rated value (DC) | 24 V | 24 V | 24 V | 24 V |
permissible range, lower limit (DC) | 19.2 V | 19.2 V | 19.2 V | 19.2 V |
permissible range, upper limit (DC) | 28.8 V | 28.8 V | 28.8 V | 28.8 V |
Reverse polarity protection | Yes | Yes | Yes | Yes |
Input current | ||||
Current consumption, max. | 70 mA; All channels are supplied from the encoder supply | 50 mA; All channels are supplied from the encoder supply | 90 mA | |
Encoder supply | ||||
Number of outputs | 8 | 8 | ||
Output voltage, min. | 19.2 V | 19.2 V | ||
Short-circuit protection | Yes; per module | No | Yes; per module | |
24 V encoder supply | ||||
● 24 V
|
Yes | Yes | No | |
● Short-circuit protection
|
Yes | Yes | ||
● Output current, max.
|
700 mA | |||
● Output current per channel, max.
|
700 mA | 700 mA | ||
● Output current per module, max.
|
700 mA | 700 mA | ||
Power loss | ||||
Power loss, typ. | 1.6 W; 24 V, 8 inputs supplied via encoder supply | 1.5 W | 1 W; 24 V, 8 inputs supplied via encoder supply | 1.7 W |
Address area | ||||
Address space per module | ||||
● Inputs
|
1 byte | 1 byte | 1 byte; + 1 byte for QI information | 2 byte; + 2 bytes for QI information |
Hardware configuration | ||||
Automatic encoding | Yes | Yes | Yes | Yes |
● Mechanical coding element
|
Yes | Yes | Yes | |
● Type of mechanical coding element
|
Type A | type B | Type A | Type A |
Selection of BaseUnit for connection variants | ||||
● 1-wire connection
|
BU type A0 | BU type A0 | BU type A0 | BU type A0 |
● 2-wire connection
|
BU type A0 | BU type A0 | BU type A0 | BU type A0 + Potential isolation module |
● 3-wire connection
|
BU type A0 with AUX terminals or potential distributor module | BU type A0 with AUX terminals or potential distributor module | BU type A0 with AUX terminals or potential distributor module | BU type A0 + Potential isolation module |
● 4-wire connection
|
BU type A0 + Potential isolation module | BU type A0 + Potential isolation module | BU type A0 + Potential isolation module | BU type A0 + Potential isolation module |
Digital inputs | ||||
Number of digital inputs | 8 | 8 | 8 | 16 |
Digital inputs, parameterizable | Yes | Yes | Yes | Yes |
Source/sink input | P-reading | Sourcing | P-reading | P-reading |
Input characteristic curve in accordance with IEC 61131, type 1 | Yes | Yes | ||
Input characteristic curve in accordance with IEC 61131, type 2 | Yes | |||
Input characteristic curve in accordance with IEC 61131, type 3 | Yes | Yes | Yes | |
Input voltage | ||||
● Rated value (DC)
|
24 V | 24 V | 24 V | 24 V |
— 24 V DC
|
Yes | Yes | Yes | Yes |
● for signal “0”
|
-30 to +5 V | 30 V to -5 V (reference potential is L+) | -30 to +5 V | -30 to +5 V |
● for signal “1”
|
+11 to +30V | -11 V to -30 V (reference potential is L+) | +11 to +30V | +11 to +30V |
Input current | ||||
● for signal “1”, typ.
|
6.8 mA | 6 mA | 2.5 mA | 2.5 mA |
