Siemens PLCs SIMATIC S7-300 Counter module FM 350-1 6ES7350-1AH03-0AE0

Series#: Siemens PLC

Product Details

  • Siemens PLCs SIMATIC S7-300 Counter module FM 350-1 6ES7350-1AH03-0AE0
  • We are First Class Siemens Supplier,siemens plc dealer and Siemens plc distributor in China.
  • We can Supply Siemens automation parts,such as Siemens PLC,Siemens Servo Motor,Siemens HMI,Siemens VFD and So on,
  • 100% Original and new,In stock by Siemens Automation
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Qty:

Specification

Article number 6ES7350-1AH03-0AE0
FM350-1, counter mod. up to 500KHZ
Supply voltage
Auxiliary voltage 1L+, load voltage 2L+


● Rated value (DC)



24 V


● permissible range, lower limit (DC)



20.4 V; Dynamic 18.5 V


● permissible range, upper limit (DC)



28.8 V; dynamic 30.2 V
Input current
from load voltage 1L+ (without load), max. 40 mA
from backplane bus 5 V DC, max. 160 mA
Encoder supply
5 V encoder supply


● 5 V



Yes; 5.2 V ±2 %


● Output current, max.



300 mA
24 V encoder supply


● 24 V



Yes; 1L+ (-3 V)


● Output current, max.



400 mA
Power loss
Power loss, typ. 4.5 W
Digital inputs
Number of digital inputs 3
Functions 1 for gate start, 1 for gate stop, 1 for setting the counter
Input voltage


● for signal “0”



-28.8 … +5V


● for signal “1”



+11 to +28.8V
Input current


● for signal “1”, typ.



9 mA
Digital outputs
Number of digital outputs 2
Short-circuit protection Yes; Clocked electronically
Limitation of inductive shutdown voltage to 2L+ (-39 V)
Output voltage


● for signal “0”, max.



3 V


● for signal “1”, min.



2L+ (-1,5 V)
Output current


● for signal “1” rated value



0.5 A


● for signal “1” permissible range for 0 to 60 °C, min.



5 mA


● for signal “1” permissible range for 0 to 60 °C, max.



0.6 A
Output delay with resistive load


● “0” to “1”, max.



300 µs
Encoder
Connectable encoders


● Incremental encoder (symmetrical)



Yes; With 2 pulse trains offset by 90°


● Incremental encoder (asymmetrical)



Yes


● 24 V initiator



Yes


● 24 V directional element



Yes; 1 pulse train, 1 direction level
Counter
Number of counter inputs 1; 32 bit or ±31 bit
Counter input 5 V


● Type



RS 422


● Terminating resistor



220 Ω


● Differential input voltage



1,3 V


● Counting frequency, max.



500 kHz
Counter input 24 V


● Input voltage for signal “0”



-28.8 … +5V


● Input voltage for signal “1”



+11 to +28.8V


● Input current for signal “1”, typ.



9 mA


● Counting frequency, max.



200 kHz


● Minimum pulse width



2.5 µs
Potential separation
Potential separation digital inputs


● between the channels and backplane bus



Yes; Optocoupler
Potential separation digital outputs


● between the channels and backplane bus



Yes; Optocoupler
Potential separation counter


● between the channels and backplane bus



Yes; Optocoupler
Isolation
Isolation tested with 500 V
Connection method
required front connector 1x 20-pin
Dimensions
Width 40 mm
Height 125 mm
Depth 120 mm
Weights
Weight, approx. 250 g
