Article number | 6ES7326-1RF01-0AB0 | 6ES7326-1BK02-0AB0 |
SM326, 8DE, DC24V, failsafe | SM326, F-DI 24 X DC24V, failsafe | |
Supply voltage | ||
Rated value (DC) | 24 V | |
Reverse polarity protection | Yes | Yes |
Input current | ||
from load voltage L+ (without load), max. | 160 mA | 450 mA |
from backplane bus 5 V DC, max. | 90 mA | 100 mA |
Encoder supply | ||
Number of outputs | 8 | 4; Isolated |
Type of output voltage | 8.2 V DC | |
Output current | ||
● Rated value
|
400 mA | |
Power loss | ||
Power loss, typ. | 4.5 W | 10 W |
Digital inputs | ||
Number of digital inputs | 8 | 24 |
Number of simultaneously controllable inputs | ||
all mounting positions | ||
— up to 40 °C, max.
|
8 | 24 |
— up to 60 °C, max.
|
8 | 24; (at 24 V) or 18 (at 28.8 V) |
Input voltage | ||
● Type of input voltage
|
DC | DC |
● Rated value (DC)
|
24 V | |
● for signal “0”
|
-30 to +5 V | |
● for signal “1”
|
+11 to +30V | |
Input current | ||
● for signal “0”, max. (permissible quiescent current)
|
0.35 to 1.2 mA | 2 mA |
● for signal “1”, typ.
|
2.1 to 7 mA | 10 mA |
Input delay (for rated value of input voltage) | ||
for standard inputs | ||
— at “0” to “1”, max.
|
3.4 ms | |
— at “1” to “0”, max.
|
3.4 ms | |
for NAMUR inputs | ||
— at “0” to “1”, max.
|
1.2 to 3 ms | |
— at “1” to “0”, max.
|
1.2 to 3 ms | |
Cable length | ||
● shielded, max.
|
200 m | 200 m |
● unshielded, max.
|
100 m | 100 m |
Encoder | ||
Connectable encoders | ||
● 2-wire sensor
|
Yes; if short-circuit test is deactivated | |
— permissible quiescent current (2-wire sensor), max.
|
2 mA | |
Interrupts/diagnostics/status information | ||
Diagnostics function | Yes | |
Alarms | ||
● Diagnostic alarm
|
Yes; Parameterizable | Yes |
Diagnoses | ||
● Diagnostic information readable
|
Yes | |
Diagnostics indication LED | ||
● Fail-safe operation
|
Yes | Yes |
● Group error SF (red)
|
Yes | Yes |
Ex(i) characteristics | ||
Module for Ex(i) protection | Yes | |
Maximum values of input circuits (per channel) | ||
● Co (permissible external capacity), max.
|
3 µF | |
● Io (short-circuit current), max.
|
13.9 mA | |
● Lo (permissible external inductivity), max.
|
80 mH | |
● Po (power of load), max.
|
33.1 mW | |
● Uo (output no-load voltage), max.
|
10 V | |
● Um (fault voltage), max.
|
60 V DC/30 V AC | |
● Ta (permissible ambient temperature), max.
|
60 °C | 60 °C |
