| Rated value (DC) | 24 V; 1L+ | 24 V; 1L+ |
| Reverse polarity protection | Yes | Yes |
| Load voltage L+ | ||
|
● Rated value (DC)
|
24 V; 2L+, 3L+ | 24 V; 2L+, 3L+ |
|
● Reverse polarity protection
|
No | No |
| Input current | ||
| from supply voltage 1L+, max. | 100 mA | 75 mA |
| from load voltage 2L+ (without load), max. | 100 mA | 100 mA |
| from load voltage 3L+ (without load), max. | 100 mA | 100 mA |
| from backplane bus 5 V DC, max. | 100 mA | 100 mA |
| Power loss | ||
| Power loss, typ. | 6 W | 12 W |
| Digital outputs | ||
| Number of digital outputs | 10 | 8 |
| Short-circuit protection | Yes | Yes |
| Limitation of inductive shutdown voltage to | L+ (-33 V) | |
| Switching capacity of the outputs | ||
|
● on lamp load, max.
|
5 W | 5 W |
| Output voltage | ||
|
● for signal “1”, min.
|
L+ (-1.0 V) | L+ (-1.0 V) |
| Output current | ||
|
● for signal “1” rated value
|
2 A | 2 A |
|
● for signal “1” permissible range for 0 to 40 °C, min.
|
7 mA | 7 mA |
|
● for signal “1” permissible range for 0 to 40 °C, max.
|
2.4 A | 2 A; 2 A for horizontal installation, 1 A for vertical installation |
|
● for signal “1” permissible range for 40 to 60 °C, min.
|
7 mA | 7 mA |
|
● for signal “1” permissible range for 40 to 60 °C, max.
|
2.4 A | 1 A; for horizontal installation |
|
● for signal “0” residual current, max.
|
0.5 mA | 0.5 mA |
| Switching frequency | ||
|
● with resistive load, max.
|
25 Hz | 30 Hz |
|
● with inductive load, max.
|
25 Hz | 2 Hz |
|
● on lamp load, max.
|
10 Hz | 10 Hz |
| Total current of the outputs (per group) | ||
| horizontal installation | ||
|
— up to 40 °C, max.
|
10 A | 7.5 A |
|
— up to 60 °C, max.
|
6 A | 5 A |
| vertical installation | ||
|
— up to 40 °C, max.
|
5 A | 5 A |
| Cable length | ||
|
● shielded, max.
|
1 000 m | 200 m; 200 m for SIL 3, AK 6, Cat 4 |
|
● unshielded, max.
|
600 m | 200 m |
| Interrupts/diagnostics/status information | ||
| Alarms | ||
|
● Diagnostic alarm
|
Yes | Yes; Parameterizable |
| Diagnoses | ||
|
● Diagnostic information readable
|
Yes | Yes |
| Diagnostics indication LED | ||
|
● Fail-safe operation
|
Yes | Yes |
|
● Group error SF (red)
|
Yes | Yes |
| Potential separation | ||
| Potential separation digital outputs | ||
|
● between the channels
|
Yes | Yes |
|
● between the channels, in groups of
|
5 | 4 |
|
● between the channels and backplane bus
|
Yes | Yes |
|
● between the channels and the power supply of the electronics
|
Yes | Yes |
| Isolation | ||
| Isolation tested with | 370V for 1 min | 500 V DC/350 V AC |
| Standards, approvals, certificates | ||
| Highest safety class achievable in safety mode | ||
|
● acc. to DIN VDE 0801
|
AK 5 and 6 | |
|
● acc. to EN 954
|
Cat. 4 | Cat. 4 |
|
● Performance level according to ISO 13849-1
|
e | e |
|
● SIL acc. to IEC 61508
|
SIL 3 | SIL 3 |
| Connection method | ||
| required front connector | 40-pin | 40-pin |
| Dimensions | ||
| Width | 40 mm | 80 mm |
| Height | 125 mm | 125 mm |
| Depth | 120 mm | 120 mm |
| Weights | ||
| Weight, approx. | 330 g | 465 g |
