| Article number | 6ES7455-0VS00-0AE0 | 6ES7455-1VS00-0AE0 |
| Article number | SIMATIC S7-400, CONTROL MODULE | SIMATIC S7-400, CONTROL MODULE |
| Supply voltage | ||
| Load voltage L+ | ||
|
● Rated value (DC)
|
24 V | 24 V |
|
● permissible range, lower limit (DC)
|
20.4 V | 20.4 V |
|
● permissible range, upper limit (DC)
|
28.8 V | 28.8 V |
| Input current | ||
| from load voltage L+ (without load), max. | 440 mA; typ. 370 mA | 400 mA; typ. 330 mA |
| Power loss | ||
| Power loss, typ. | 12 W | 10.7 W |
| Digital inputs | ||
| Number of digital inputs | 16 | 16 |
| Input characteristic curve in accordance with IEC 61131, type 2 | Yes | Yes |
| Input voltage | ||
|
● Rated value (DC)
|
24 V | 24 V |
|
● for signal “0”
|
-3 to +5V | -3 to +5V |
|
● for signal “1”
|
13 to 30V | 13 to 30V |
| Input current | ||
|
● for signal “1”, typ.
|
7 mA | 7 mA |
| Cable length | ||
|
● shielded, max.
|
1 000 m | 1 000 m |
|
● unshielded, max.
|
600 m | 600 m |
| Digital outputs | ||
| Number of digital outputs | 32 | |
| Short-circuit protection | Yes; Electronic | |
| Limitation of inductive shutdown voltage to | L+ (-1.5 V) | |
| Controlling a digital input | Yes | |
| Switching capacity of the outputs | ||
|
● on lamp load, max.
|
5 W | |
| Load resistance range | ||
|
● lower limit
|
240 Ω | |
|
● upper limit
|
4 kΩ | |
| Output voltage | ||
|
● for signal “1”, min.
|
L+ (-2.5 V) | |
| Output current | ||
|
● for signal “1” rated value
|
0.1 A | |
|
● for signal “1” permissible range for 0 to 60 °C, min.
|
5 mA | |
|
● for signal “1” permissible range for 0 to 60 °C, max.
|
150 mA | |
|
● for signal “0” residual current, max.
|
0.5 mA | |
| Parallel switching of two outputs | ||
|
● for logic links
|
Yes | |
| Switching frequency | ||
|
● with resistive load, max.
|
100 Hz | |
|
● with inductive load, max.
|
0.5 Hz | |
|
● on lamp load, max.
|
100 Hz | |
| Cable length | ||
|
● shielded, max.
|
1 000 m | |
|
● unshielded, max.
|
600 m | |
| Analog inputs | ||
| Number of analog inputs | 16; With thermocouples or 2-wire connection; 8 with Pt 100 or 4-wire connection | 16; With thermocouples or 2-wire connection; 8 with Pt 100 or 4-wire connection |
| permissible input voltage for voltage input (destruction limit), max. | 20 V | 20 V |
| permissible input current for current input (destruction limit), max. | 40 mA | 40 mA |
| Input ranges | ||
|
● Voltage
|
Yes | Yes |
|
● Current
|
Yes | Yes |
|
● Thermocouple
|
Yes | Yes |
|
● Resistance thermometer
|
Yes | Yes |
| Input ranges (rated values), voltages | ||
|
● 0 to +10 V
|
Yes | Yes |
|
— Input resistance (0 to 10 V)
|
100 kΩ | 100 kΩ |
|
● -1.75 V to +11.75 V
|
Yes | Yes |
|
— Input resistance (-1.75 V to +11.75 V)
|
100 kΩ | 100 kΩ |
|
● -80 mV to +80 mV
|
Yes | Yes |
|
— Input resistance (-80 mV to +80 mV)
|
10 MΩ | 10 MΩ |
| Input ranges (rated values), currents | ||
|
● 0 to 20 mA
|
Yes | Yes |
|
— Input resistance (0 to 20 mA)
|
50 Ω | 50 Ω |
|
● 0 to 23.5 mA
|
Yes | Yes |
|
— Input resistance (0 to 23.5 mA)
|
50 Ω | 50 Ω |
|
● -3.5 mA to +23.5 mA
|
Yes | Yes |
|
— Input resistance (-3.5 mA to +23.5 mA)
|
50 Ω | 50 Ω |
|
● 4 mA to 20 mA
|
Yes | Yes |
|
— Input resistance (4 mA to 20 mA)
|
50 Ω | 50 Ω |
| Input ranges (rated values), thermocouples | ||
|
● Type B
|
Yes | Yes |
|
— Input resistance (Type B)
|
10 MΩ | 10 MΩ |
|
● Type J
|
Yes | Yes |
|
— Input resistance (type J)
|
10 MΩ | 10 MΩ |
|
● Type K
|
Yes | Yes |
|
— Input resistance (Type K)
|
10 MΩ | 10 MΩ |
|
● Type R
|
Yes | Yes |
|
— Input resistance (Type R)
|
10 MΩ | 10 MΩ |
|
● Type S
|
Yes | Yes |
|
— Input resistance (Type S)
|
10 MΩ | 10 MΩ |
| Input ranges (rated values), resistance thermometer | ||
|
● Pt 100
|
Yes | Yes |
|
— Input resistance (Pt 100)
|
10 MΩ | 10 MΩ |
| Thermocouple (TC) | ||
| Temperature compensation | ||
|
— internal temperature compensation
|
Yes; Parameterizable | Yes; Parameterizable |
|
— external temperature compensation with Pt100
|
Yes; Parameterizable | Yes; Parameterizable |
| Characteristic linearization | ||
|
● parameterizable
|
Yes | Yes |
|
— for thermocouples
|
Type B, J, K, R, S | Type B, J, K, R, S |
|
— for resistance thermometer
|
Pt100 (standard) | Pt100 (standard) |
| Cable length | ||
|
● shielded, max.
|
200 m; 50 m at 80 mV and thermocouples | 200 m; 50 m at 80 mV and thermocouples |
| Analog outputs | ||
| Number of analog outputs | 16 | |
| Voltage output, short-circuit protection | Yes | |
| Voltage output, short-circuit current, max. | 25 mA | |
| Current output, no-load voltage, max. | 18 V | |
| Output ranges, voltage | ||
|
● 0 to 10 V
|
Yes | |
|
● -10 V to +10 V
|
Yes | |
| Output ranges, current | ||
|
● 0 to 20 mA
|
Yes | |
|
● -20 mA to +20 mA
|
Yes | |
|
● 4 mA to 20 mA
|
Yes | |
| Connection of actuators | ||
|
● for voltage output two-wire connection
|
Yes | |
|
● for current output two-wire connection
|
Yes | |
| Load impedance (in rated range of output) | ||
|
● with voltage outputs, min.
|
1 kΩ | |
|
● with voltage outputs, capacitive load, max.
|
1 µF | |
|
● with current outputs, max.
|
500 Ω | |
|
● with current outputs, inductive load, max.
|
1 mH | |
| Cable length | ||
|
● shielded, max.
|
200 m; 50 m at 80 mV and thermocouples | |
| Analog value generation for the inputs | ||
| Integration and conversion time/resolution per channel | ||
|
● Resolution with overrange (bit including sign), max.
|
14 bit; 12 bit or 14 bit, parameterizable | 14 bit; 12 bit or 14 bit, parameterizable |
