Article number | 6ES7322-5GH00-0AB0 | 6ES7322-1CF00-0AA0 | 6ES7322-1BF01-0AA0 | 6ES7322-1FF01-0AA0 | 6ES7322-5FF00-0AB0 | 6ES7322-1FH00-0AA0 |
SM322, 16DO, AC/DC24-48V, 0,5A | SM322, 8DO, 48-125V DC, 1,5A | SM322, 8DO, 24V DC, 2A | SM322, 8DO, 120/230V AC, 1A | SM322, 8DO, AC120/230V, 2A | SM322, 16DO, 120/230V AC, 1A | |
Supply voltage | ||||||
Mains buffering | ||||||
● Mains/voltage failure stored energy time
|
5 ms | |||||
Load voltage L+ | ||||||
● Rated value (DC)
|
24 V; 24 / 48 | 48 V; 48 V DC to 125 V DC | 24 V | |||
● permissible range, lower limit (DC)
|
20.4 V | 40 V | 20.4 V | |||
● permissible range, upper limit (DC)
|
57.6 V | 140 V | 28.8 V | |||
● Reverse polarity protection
|
Yes | Yes; through fuse | ||||
Load voltage L1 | ||||||
● Rated value (AC)
|
230 V; 120/230 V AC | 230 V; 120/230 V AC | 230 V; 120/230 V AC | |||
● permissible range, lower limit (AC)
|
93 V | 79 V | 79 V | |||
● permissible range, upper limit (AC)
|
264 V | 264 V | 264 V | |||
● permissible frequency range, lower limit
|
47 Hz | |||||
● permissible frequency range, upper limit
|
63 Hz | |||||
Input current | ||||||
from supply voltage L+, max. | 200 mA | |||||
from load voltage L+ (without load), max. | 2 mA | 60 mA | ||||
from load voltage L1 (without load), max. | 2 mA | 2 mA | 2 mA | |||
from backplane bus 5 V DC, max. | 100 mA | 100 mA | 40 mA | 100 mA | 100 mA | 200 mA |
Power loss | ||||||
Power loss, typ. | 2.8 W | 7.2 W | 6.8 W | 8.6 W | 8.6 W | 8.6 W |
Digital outputs | ||||||
Number of digital outputs | 16 | 8 | 8 | 8 | 8 | 16 |
Short-circuit protection | No; to be provided externally | Yes; Electronic | Yes; Electronic | Yes; Fuse 8 A, 250 V; per group | Yes; to be provided externally; fuse 3.15 A / 250 V, quick response | Yes; Fuse 8 A, 250 V; per group |
● Response threshold, typ.
|
4.4 A | 3 A | ||||
● required current for fuse shutdown, min.
|
40 A | 40 A | ||||
● Response time, max.
|
300 ms | 300 ms | ||||
Limitation of inductive shutdown voltage to | M (-1 V) | L+ (-48 V) | ||||
Controlling a digital input | Yes | Yes | Yes | Yes | Yes | Yes |
Size of motor starters according to NEMA, max. | Size 5 according to NEMA | 5 NEMA compliant | Size 5 according to NEMA | 4 NEMA compliant | ||
Spare fuses | 6.3 A / 250 V, quick-response, 5x 20 mm | 8 A / quick response | 8 A / quick response | |||
Zero-crossing switch | Yes; Max. 60 V | Yes; 60 V | ||||
Switching capacity of the outputs | ||||||
● on lamp load, max.
|
2.5 W | 15 W; 15 W (48 V) or 40 W (125 V) | 10 W | 50 W | 50 W | 50 W |
Load resistance range | ||||||
● lower limit
|
12 Ω | |||||
● upper limit
|
4 kΩ | |||||
Output voltage | ||||||
● for signal “1”, min.
|
L+ (-0.25 V) | L+ (-1.2 V) | L+ (-0.8 V) | L1 (-1.5 V) | L1 (-8.5 V) | |
● for signal “1” (at max. current), min.
|
L1 (-1.5 V) | L1 (-1.5 V) | ||||
● for signal “1” (at min. current), min.
|
L1 (-8.5 V) | L1 (-8.5 V) | ||||
Output current | ||||||
● for signal “1” rated value
|
0.5 A | 1.5 A | 2 A | 2 A | 2 A | 1 A |
● for signal “1” permissible range for 0 to 40 °C, min.
|
10 mA | 5 mA | 10 mA | 10 mA | 10 mA | |
● for signal “1” permissible range for 0 to 40 °C, max.
|
0.5 A | 1.5 A | 2.4 A | 2 A | 2 A | 1 A |
● for signal “1” permissible range for 40 to 60 °C, min.
|
10 mA | 5 mA | 10 mA | 10 mA | 10 mA | |
● for signal “1” permissible range for 40 to 60 °C, max.
|
0.5 A | 1.5 A | 2.4 A | 1 A | 1 A | 0.5 A |
● for signal “1” minimum load current
|
10 mA | 5 mA | 10 mA | 10 mA | 10 mA | |
● for signal “1” permissible surge current, max.
|
1.5 A; for 50 ms, 1 A 2 s one-time | 3 A; for 10 ms | 20 A; max. 1 AC cycle | 20 A; with 2 half waves | 20 A; with 2 half waves | |
● for signal “0” residual current, max.
|
10 µA | 0.5 mA | 0.5 mA | 2 mA | 2 mA | 2 mA |
Output delay with resistive load | ||||||
● “0” to “1”, max.
|
6 ms | 2 ms | 100 µs | 1 AC cycle | ||
● “1” to “0”, max.
|
3 ms | 15 ms | 500 µs | 1 AC cycle | ||
Parallel switching of two outputs | ||||||
● for uprating
|
No | No | No | No | No | No |
● for redundant control of a load
|
Yes | Yes; only outputs of the same group | Yes | Yes | Yes | Yes; only outputs of the same group |
Switching frequency | ||||||
● with resistive load, max.
|
10 Hz | 25 Hz | 100 Hz | 10 Hz | 10 Hz | 10 Hz |
● with inductive load, max.
|
0.5 Hz | 0.5 Hz | 0.5 Hz | 0.5 Hz | 0.5 Hz | 0.5 Hz |
● with inductive load (acc. to IEC 60947-5-1, DC13), max.
|
0.5 Hz | 0.5 Hz | 0.5 Hz | |||
● with inductive load (acc. to IEC 60947-5-1, AC15), max.
|
0.5 Hz | 0.5 Hz | 0.5 Hz | |||
● on lamp load, max.
|
0.5 Hz | 10 Hz | 10 Hz | 1 Hz | 1 Hz | 1 Hz |
Total current of the outputs (per group) | ||||||
horizontal installation | ||||||
— up to 40 °C, max.
|
0.5 A; 8 A per module | 6 A | 4 A | 4 A | 8 A | 4 A |
— up to 50 °C, max.
|
4 A | |||||
— up to 60 °C, max.
|
0.5 A; 8 A per module | 3 A | 4 A | 2 A | 4 A | 2 A |
vertical installation | ||||||
— up to 40 °C, max.
|
0.5 A; 8 A per module | 4 A | 4 A | 2 A | 4 A | 2 A |
Cable length | ||||||
● shielded, max.
|
1 000 m | 1 000 m | 1 000 m | 1 000 m | 1 000 m | 1 000 m |
● unshielded, max.
|
600 m | 600 m | 600 m | 600 m | 600 m | 600 m |
