Siemens PLCs SM 322 output modules 6ES7322-5FF00-0AB0 6ES7322-1FH00-0AA0

Series#: Siemens PLC

Product Details

  • Siemens PLCs SM 322 output modules 6ES7322-5FF00-0AB0 6ES7322-1FH00-0AA0
  • Siemens PLC Controller Module LOGO Series
  • We are First Class Siemens Supplier,siemens plc dealer and Siemens plc distributor in China.
  • We can Supply Siemens automation parts,such as Siemens PLC,Siemens Servo Motor,Siemens HMI,Siemens VFD and So on,
  • 100% Original and new,In stock by Siemens Automation
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Qty:

Specification

Article number 6ES7322-5GH00-0AB0 6ES7322-1CF00-0AA0 6ES7322-1BF01-0AA0 6ES7322-1FF01-0AA0 6ES7322-5FF00-0AB0 6ES7322-1FH00-0AA0
SM322, 16DO, AC/DC24-48V, 0,5A SM322, 8DO, 48-125V DC, 1,5A SM322, 8DO, 24V DC, 2A SM322, 8DO, 120/230V AC, 1A SM322, 8DO, AC120/230V, 2A SM322, 16DO, 120/230V AC, 1A
Supply voltage
Mains buffering


● Mains/voltage failure stored energy time



5 ms
Load voltage L+


● Rated value (DC)



24 V; 24 / 48 48 V; 48 V DC to 125 V DC 24 V


● permissible range, lower limit (DC)



20.4 V 40 V 20.4 V


● permissible range, upper limit (DC)



57.6 V 140 V 28.8 V


● Reverse polarity protection



Yes Yes; through fuse
Load voltage L1


● Rated value (AC)



230 V; 120/230 V AC 230 V; 120/230 V AC 230 V; 120/230 V AC


● permissible range, lower limit (AC)



93 V 79 V 79 V


● permissible range, upper limit (AC)



264 V 264 V 264 V


● permissible frequency range, lower limit



47 Hz


● permissible frequency range, upper limit



63 Hz
Input current
from supply voltage L+, max. 200 mA
from load voltage L+ (without load), max. 2 mA 60 mA
from load voltage L1 (without load), max. 2 mA 2 mA 2 mA
from backplane bus 5 V DC, max. 100 mA 100 mA 40 mA 100 mA 100 mA 200 mA
Power loss
Power loss, typ. 2.8 W 7.2 W 6.8 W 8.6 W 8.6 W 8.6 W
Digital outputs
Number of digital outputs 16 8 8 8 8 16
Short-circuit protection No; to be provided externally Yes; Electronic Yes; Electronic Yes; Fuse 8 A, 250 V; per group Yes; to be provided externally; fuse 3.15 A / 250 V, quick response Yes; Fuse 8 A, 250 V; per group


● Response threshold, typ.



4.4 A 3 A


● required current for fuse shutdown, min.



40 A 40 A


● Response time, max.



300 ms 300 ms
Limitation of inductive shutdown voltage to M (-1 V) L+ (-48 V)
Controlling a digital input Yes Yes Yes Yes Yes Yes
Size of motor starters according to NEMA, max. Size 5 according to NEMA 5 NEMA compliant Size 5 according to NEMA 4 NEMA compliant
Spare fuses 6.3 A / 250 V, quick-response, 5x 20 mm 8 A / quick response 8 A / quick response
Zero-crossing switch Yes; Max. 60 V Yes; 60 V
Switching capacity of the outputs


● on lamp load, max.



2.5 W 15 W; 15 W (48 V) or 40 W (125 V) 10 W 50 W 50 W 50 W
Load resistance range


● lower limit



12 Ω


● upper limit



4 kΩ
Output voltage


● for signal “1”, min.



L+ (-0.25 V) L+ (-1.2 V) L+ (-0.8 V) L1 (-1.5 V) L1 (-8.5 V)


● for signal “1” (at max. current), min.



L1 (-1.5 V) L1 (-1.5 V)


● for signal “1” (at min. current), min.



L1 (-8.5 V) L1 (-8.5 V)
Output current


● for signal “1” rated value



0.5 A 1.5 A 2 A 2 A 2 A 1 A


● for signal “1” permissible range for 0 to 40 °C, min.



10 mA 5 mA 10 mA 10 mA 10 mA


● for signal “1” permissible range for 0 to 40 °C, max.



0.5 A 1.5 A 2.4 A 2 A 2 A 1 A


● for signal “1” permissible range for 40 to 60 °C, min.



10 mA 5 mA 10 mA 10 mA 10 mA


● for signal “1” permissible range for 40 to 60 °C, max.



0.5 A 1.5 A 2.4 A 1 A 1 A 0.5 A


● for signal “1” minimum load current



10 mA 5 mA 10 mA 10 mA 10 mA


● for signal “1” permissible surge current, max.



1.5 A; for 50 ms, 1 A 2 s one-time 3 A; for 10 ms 20 A; max. 1 AC cycle 20 A; with 2 half waves 20 A; with 2 half waves


● for signal “0” residual current, max.



10 µA 0.5 mA 0.5 mA 2 mA 2 mA 2 mA
Output delay with resistive load


● “0” to “1”, max.



6 ms 2 ms 100 µs 1 AC cycle


● “1” to “0”, max.



3 ms 15 ms 500 µs 1 AC cycle
Parallel switching of two outputs


● for uprating



No No No No No No


● for redundant control of a load



Yes Yes; only outputs of the same group Yes Yes Yes Yes; only outputs of the same group
Switching frequency


● with resistive load, max.



10 Hz 25 Hz 100 Hz 10 Hz 10 Hz 10 Hz


● with inductive load, max.



0.5 Hz 0.5 Hz 0.5 Hz 0.5 Hz 0.5 Hz 0.5 Hz


● with inductive load (acc. to IEC 60947-5-1, DC13), max.



0.5 Hz 0.5 Hz 0.5 Hz


● with inductive load (acc. to IEC 60947-5-1, AC15), max.



0.5 Hz 0.5 Hz 0.5 Hz


● on lamp load, max.



0.5 Hz 10 Hz 10 Hz 1 Hz 1 Hz 1 Hz
Total current of the outputs (per group)
horizontal installation


— up to 40 °C, max.



0.5 A; 8 A per module 6 A 4 A 4 A 8 A 4 A


— up to 50 °C, max.



4 A


— up to 60 °C, max.



0.5 A; 8 A per module 3 A 4 A 2 A 4 A 2 A
vertical installation


— up to 40 °C, max.



0.5 A; 8 A per module 4 A 4 A 2 A 4 A 2 A
Cable length


● shielded, max.



1 000 m 1 000 m 1 000 m 1 000 m 1 000 m 1 000 m


● unshielded, max.



600 m 600 m 600 m 600 m 600 m 600 m
