Siemens S7-1200 PLCs CPU 1211C 6ES7211-1HE40-0XB0

Series#: Siemens PLC

Product Details

Siemens S7-1200 PLCs CPU 1211C 6ES7211-1HE40-0XB0
We are First Class Siemens Supplier,siemens plc dealer and siemens plc distributor in China.
We can Supply Siemens automation parts,such as Siemens PLC,Siemens Servo Motor,Siemens HMI,Siemens VFD and So on,
100% Original and new,In stock by Siemens Automation
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Article number	6ES7211-1BE40-0XB0	6ES7211-1AE40-0XB0	6ES7211-1HE40-0XB0
	CPU 1211C, AC/DC/Relay, 6DI/4DO/2AI	CPU 1211C, DC/DC/DC, 6DI/4DO/2AI	CPU 1211C, DC/DC/Relay, 6DI/4DO/2AI
General information
Product type designation	CPU 1211C AC/DC/relay	CPU 1211C DC/DC/DC	CPU 1211C DC/DC/relay
Firmware version	V4.4	V4.4	V4.4
Engineering with
·● Programming package ·	STEP 7 V16 or higher	STEP 7 V16 or higher	STEP 7 V16 or higher
Input current
Current consumption (rated value)	60 mA at 120 V AC; 30 mA at 240 V AC	300 mA; CPU only	300 mA; CPU only
Current consumption, max.	180 mA at 120 V AC; 90 mA at 240 V AC	900 mA; CPU with all expansion modules	900 mA; CPU with all expansion modules
Inrush current, max.	20 A; at 264 V	12 A; at 28.8 V DC	12 A; at 28.8 V DC
I²t	0.8 A²·s	0.5 A²·s	0.8 A²·s
Output current
for backplane bus (5 V DC), max.	750 mA; Max. 5 V DC for CM	750 mA; Max. 5 V DC for CM	750 mA; Max. 5 V DC for CM
·● Plug-in (SIMATIC Memory Card), max. ·	with SIMATIC memory card	with SIMATIC memory card	with SIMATIC memory card
CPU processing times
for bit operations, typ.	0.08 µs; / instruction	0.08 µs; / instruction	0.08 µs; / instruction
for word operations, typ.	1.7 µs; / instruction	1.7 µs; / instruction	1.7 µs; / instruction
for floating point arithmetic, typ.	2.3 µs; / instruction	2.3 µs; / instruction	2.3 µs; / instruction
CPU-blocks
Number of blocks (total)	DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used	DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used	DBs, FCs, FBs, counters and timers. The maximum number of addressable blocks ranges from 1 to 65535. There is no restriction, the entire working memory can be used
OB
·● Number, max. ·	Limited only by RAM for code	Limited only by RAM for code	Limited only by RAM for code
Data areas and their retentivity
Retentive data area (incl. timers, counters, flags), max.	10 kbyte	10 kbyte	10 kbyte
Flag
·● Number, max. ·	4 kbyte; Size of bit memory address area	4 kbyte; Size of bit memory address area	4 kbyte; Size of bit memory address area
Local data
·● per priority class, max. ·	16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB	16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB	16 kbyte; Priority class 1 (program cycle): 16 KB, priority class 2 to 26: 6 KB
Input delay (for rated value of input voltage)
for standard inputs
·— parameterizable ·	0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms and 12.8 ms, selectable in groups of four	0.1 / 0.2 / 0.4 / 0.8 / 1.6 / 3.2 / 6.4 / 10.0 / 12.8 / 20.0 μs; 0.05 / 0.1 / 0.2 / 0.4 / 0.8 / 1.6 / 3.2 / 6.4 / 10.0 / 12.8 / 20.0 ms	0.2 ms, 0.4 ms, 0.8 ms, 1.6 ms, 3.2 ms, 6.4 ms and 12.8 ms, selectable in groups of four
·— at “0” to “1”, min. ·	0.2 ms	0.2 ms	0.2 ms
·— at “0” to “1”, max. ·	12.8 ms	12.8 ms	12.8 ms
for interrupt inputs
·— parameterizable ·	Yes	Yes	Yes
for technological functions
·— parameterizable ·	Single phase : 3 @ 100 kHz, differential: 3 @ 80 kHz	Single phase : 3 @ 100 kHz, differential: 3 @ 80 kHz	Single phase : 3 @ 100 kHz, differential: 3 @ 80 kHz
Cable length
·● shielded, max. ·	500 m; 50 m for technological functions	500 m; 50 m for technological functions	500 m; 50 m for technological functions
·● unshielded, max. ·	300 m; for technological functions: No	300 m; for technological functions: No	300 m; for technological functions: No
Digital outputs
·— Number of IO Devices that can be simultaneously activated/deactivated, max. ·	8	8	8
·— Updating time ·	The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data.	The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data.	The minimum value of the update time also depends on the communication component set for PROFINET IO, on the number of IO devices and the quantity of configured user data.
PROFIBUS	Yes; CM 1243-5 (master) or CM 1242-5 (slave) required	Yes; CM 1243-5 (master) or CM 1242-5 (slave) required	Yes; CM 1243-5 (master) or CM 1242-5 (slave) required
AS-Interface	Yes; CM 1243-2 required	Yes; CM 1243-2 required	Yes; CM 1243-2 required
Protocols (Ethernet)
Weights
Weight, approx.	420 g	370 g	380 g
