Article number | 6ES7223-0BD30-0XB0 | 6ES7223-3AD30-0XB0 | 6ES7223-3BD30-0XB0 |
Signal Board SB1223, 2 DI/2 DO | Signal Board SB 1223, 2DI/2DQ 5V 200KHz | Signal Board SB 1223, 2DI/2DQ 24V 200KHz | |
General information | |||
Product type designation | SB 1223, DI 2×24 V DC/DQ 2×24 V DC | SB 1223, DI 2×5 V DC/DQ 2×5 V DC 200 kHz | SB 1223, DI 2×24 V DC/DQ 2×24 V DC 200 kHz |
Supply voltage | |||
permissible range, lower limit (DC) | 20.4 V | ||
permissible range, upper limit (DC) | 28.8 V | ||
Input current | |||
from backplane bus 5 V DC, typ. | 50 mA | 35 mA | 35 mA |
Output voltage | |||
Power supply to the transmitters | |||
·
● Supply current, max. · |
4 mA; per channel | ||
Power loss | |||
Power loss, typ. | 1 W | 0.5 W | 0.5 W |
Digital inputs | |||
Number of digital inputs | 2; Current-sinking | 2; Current-sourcing | 2; Current-sourcing |
·
● in groups of · |
1 | 2 | 2 |
Input characteristic curve in accordance with IEC 61131, type 1 | Yes | ||
Number of simultaneously controllable inputs | |||
all mounting positions | |||
·
— up to 40 °C, max. · |
2 | 2 | |
Input voltage | |||
·
● Type of input voltage · |
DC | DC | DC |
·
● Rated value (DC) · |
24 V | 5 V | 24 V |
·
● for signal “0” · |
0 to 5 V | (L+ minus 1.0 V DC) … L+ | (L+ minus 5.0 V DC) … L+ |
·
● for signal “1” · |
+15 to +30 V | 0 V … (L+ minus 2.0 V DC) | 0 V … (L+ minus 10 V DC) |
Weights | |||
Weight, approx. | 40 g | 35 g | 35 g |
