Memory | Flash | 256 MB |
RAM | 256 MB | |
Processor | 32 bits RISC Cortex-A8 600MHz | |
I/O Port |
SD Card Slot | N/A |
USB Host | N/A | |
USB Client | N/A | |
Ethernet (LAN1) | 10/100/1000 Base-T x 1 | |
Ethernet (LAN2) | 10/100 Base-T x 1 | |
COM Port |
COM1: RS-232 2W COM2: RS-485 2W/4W
COM3: RS-485 2W |
|
RS-485 Dual Isolation | N/A | |
CAN Bus | N/A | |
HDMI | N/A | |
Audio Output | N/A | |
Video Input | N/A | |
RTC | Built-in | |
Power |
Input Power | 24±20%VDC |
Power Isolation | Built-in | |
Power Consumption | 230mA@24VDC | |
Voltage Resistance | 500VAC (1 min.) | |
Isolation Resistance | Exceed 50MW at 500VDC | |
Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) | |
Specification |
PCB Coating | Yes |
Enclosure | Plastic | |
Dimensions WxHxD | 109 x 81 x 27 mm | |
Weight | Approx. 0.14 kg | |
Mount | 35 mm DIN rail mounting | |
Environment |
Protection Structure | IP20 |
Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) | |
Operating Temperature | 0° ~ 50°C (32° ~ 122°F) | |
Relative Humidity | 10% ~ 90% (non-condensing) | |
Certificate | CE | CE marked |
UL | cULus Listed | |
Software | EasyBuilder Pro V5.06.01 or later versions EasyAccess 2.0 (Optional) |
