Weintek HMI cMT3103

Series#: Weinview HMI

Product Details

Qty:

Specification

Model cMT3103
Display 10.1” TFT
Resolution 1024 x 600
Brightness (cd/m2) 350
Contrast Ratio 500:1
Backlight Type LED
Backlight Life Time >50,000 hrs.
Colors 16.7M
LCD Viewing Angle (T/B/L/R) 60/60/70/70
Type 4-wire Resistive Type
Accuracy Active Area Length(X)±2%, Width(Y)±2%
Flash 4 GB
RAM 1 GB
32 bits RISC Cortex-A9 1GHz
SD Card Slot N/A
USB Host USB 2.0 x 1
USB Client N/A
Ethernet 10/100 Base-T x 1


WiFi

IEEE 802.11 b/g/n 802.11b: max 19.25 dBm 802.11g: max 13.74 dBm

802.11n: max 15.01 dBm

COM Port Con.A:COM2 RS-485 2W/4W,COM3 RS-485 2W,CAN Bus

Con.B: COM1/COM3 RS-232*

RS-485 Dual Isolation N/A
CAN Bus Yes
Audio Output N/A
Video Input N/A
Built-in
Input Power 10.5~28VDC
Power Isolation Built-in
Power Consumption 2A@12V ; 1A@24V
Voltage Resistance 500VAC (1 min.)
Isolation Resistance Exceed 50MW at 500VDC
Vibration Endurance 10 to 25Hz (X, Y, Z direction 2G 30 minutes)
PCB Coating Yes
Enclosure Plastic
Dimensions WxHxD 271 x 213 x 36.4 mm
Panel Cutout 260 x 202 mm
Weight Approx. 1.07 kg
Mount Panel mount
Protection Structure NEMA4 / IP65 Compliant Front Panel
Storage Temperature -20° ~ 60°C (-4° ~ 140°F)
Operating Temperature 0° ~ 50°C (32° ~ 122°F)
Relative Humidity 10% ~ 90% (non-condensing)
CE CE marked
UL cULus Listed
EasyBuilder Pro V6.00.02 or later versions
