| Display | 15” IPS |
| Resolution | 1024 x 768 |
| Brightness (cd/m2) | 400 |
| Contrast Ratio | 1000:1 |
| Backlight Type | LED |
| Backlight Life Time | >50,000 hrs. |
| Colors | 16.2M |
| LCD Viewing Angle (T/B/R/L) | 89/89/89/89 |
| Pixel Pitch (mm) | 0.297(H) x 0.297(V) |
| Type | Tempered Glass, Capacitive Type |
| Hardness Scale | 7H |
| Flash | 4 GB |
| RAM | 1 GB |
| Processor | Quad-core 32-bit RISC 1.6GHz |
| SD Card Slot | SD/SDHC |
| USB Host | USB 2.0 x 1 |
| USB Client | N/A |
| Ethernet | LAN 1: 10/100/1000 Base-T x 1
LAN 2: 10/100 Base-T x 1 |
| COM Port | Con.A: COM1 RS-485 2W/4W, COM3 RS-485 2W, CAN Bus Con.B: COM1 RS-232 4W, COM3 RS-232 2W* |
| RS-485 Isolation | Yes |
| CAN Bus | Yes |
| HDMI | N/A |
| Audio Output | Built-in Mono Speaker Audio Line Out – 3.5 mm jack x 1 |
| RTC | Built-in |
| Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Consumption | 1.3A@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW @ 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| PCB Coating | Yes |
| Enclosure | Front bezel: Plastic, Rear Enclosure: Aluminum |
| Dimensions WxHxD | 366 x 293 x 51.5 mm |
| Panel Cutout | 352 x 279 mm |
| Weight | Approx. 2.75 kg |
| Mount | Panel mount, VESA mount 75 x 75 mm |
| Protection Structure | NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| CE | CE marked |
| Software | EasyBuilder Pro V6.04.01 or later versions |
