Weintek HMI MT8121XE1

Series#: Weintek HMI

Product Details

  • 12.1″ 1024 x 768 TFT LCD, LEDBacklight
  • SlimDesign
  • Fan-less CoolingSystem
  • Built-in 256 MB FlashMemory
  • SD Card Slot for Expansion ofStorage
  • One USB Host Port and one USB ClientPort
  • COM1 and COM3 RS-485 Built-inIsolation
  • COM1 and COM3 RS-485 2W support MPI 187.5K, please use one at onetime
  • Built-in PowerIsolator

NEMA4 / IP66 Compliant Front Panel

Qty:

Specification





Display

Display 12.1” TFT
Resolution 1024 x 768
Brightness (cd/m2) 500
Contrast Ratio 700:1
Backlight Type LED
Backlight Life Time >50,000 hrs.
Colors 16.2M
Touch Panel Type 4-wire Resistive Type
Accuracy Active Area Length(X)±2%, Width(Y)±2%
Memory Flash 256 MB
RAM 256 MB
Processor 32 bit RISC Cortex-A8 1GHz








I/O Port

SD Card Slot SD/SDHC
USB Host USB 2.0 x 1
USB Client USB 2.0 x 1
Ethernet 10/100 Base-T x 1
COM Port COM1: RS-232/RS-485 2W/4W, COM3: RS-485 2W
RS-485 Dual Isolation Yes
CAN Bus N/A
HDMI N/A
Audio Output N/A
Video Input N/A
RTC Built-in




Power

Input Power 24±20%VDC
Power Isolation Built-in
Power Consumption 800mA@24VDC
Voltage Resistance 500VAC (1 min.)
Isolation Resistance Exceed 50MW at 500VDC
Vibration Endurance 10 to 25Hz (X, Y, Z direction 2G 30 minutes)




Specification

PCB Coating Yes
Enclosure Aluminum
Dimensions WxHxD 317 x 244 x 46 mm
Panel Cutout 305 x 231 mm
Weight Approx. 2.1 kg
Mount Panel mount, VESA mount 75 x 75 mm




Environment

Protection Structure UL Type 4X (indoor use only) / NEMA4 / IP66 Compliant Front Panel
Storage Temperature -20° ~ 60°C (-4° ~ 140°F)
Operating Temperature 0° ~ 50°C (32° ~ 122°F)
Relative Humidity 10% ~ 90% (non-condensing)
Certificate CE CE marked
UL cULus Listed
Software EasyBuilder Pro V4.00.01 or later versions
