Weintek HMI MT8150XE

Series#: Weintek HMI

Product Details

Qty:

Specification

Display 15” IPS
Resolution 1024 x 768
Brightness (cd/m2) 400
Contrast Ratio 1000:1
Backlight Type LED
Backlight Life Time >50,000 hrs.
Colors 16.2M
LCD Viewing Angle (T/B/L/R) 89/89/89/89
Pixel Pitch (mm) 0.297(H)x0.297(V)
Type 4-wire Resistive Type
Accuracy Active Area Length(X)±2%, Width(Y)±2%
Flash 256 MB
RAM 256 MB
 Processor 32-bit RISC 1GHz
SD Card Slot SD/SDHC
USB Host USB 2.0 x 1
USB Client USB 2.0 x 1
Ethernet 10/100 Base-T x 1
COM Port COM1: RS-232/RS-485 2W/4W COM3: RS-485 2W
RS-485 Dual Isolation Yes
 RTC Built-in
Input Power 24±20%VDC
Power Isolation Built-in
Power Consumption 1.2A@24VDC
Voltage Resistance 500VAC (1 min.)
Isolation Resistance Exceed 50MW @ 500VDC
Vibration Endurance 10 to 25Hz (X, Y, Z direction 2G 30 minutes)
PCB Coating Yes
Enclosure Aluminum
Dimensions WxHxD 366 x 293 x 57 mm
Panel Cutout 352 x 279 mm
Weight Approx. 2.75 kg
Mount Panel mount, VESA mount 75 x 75 mm
Protection Structure UL Type 4X (indoor use only) / NEMA4 / IP65 Compliant Front Panel
Storage Temperature -20° ~ 60°C (-4° ~ 140°F)
Operating Temperature 0° ~ 50°C (32° ~ 122°F)
Relative Humidity 10% ~ 90% (non-condensing)
CE CE marked
ATEX ATEX Zone 2/22 Category 3 G/D
UL cULus Listed
 Software EasyBuilder Pro V4.00.01 or later versions
