Yaskawa Servo Motor 750W SGMJV-08ADE6E

Yaskawa Servo Motor 750W SGMJV-08ADE6E
We are First Class Yaskawa servomotors dealer and Yaskawa servomotors distributor in China.
We can Supply Yaskawa electric automation parts,such as Yaskawa PLC,Yaskawa Servo Motor&Yaskawa servo drive,Yaskawa VFD,Yaskawa Robot and So on.
Support All seriesl Yaskawa ∑5 SGMGV Rotary Servomotor,Yaskawa ∑5 SGMJV Rotary Servomoto,Yaskawa ∑7 SGM7G Rotary Servomotor,Yaskawa ∑7 SGM7J Rotary Servomotor
100% Original and new,In stock by Yaskawa Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Yaskawa Servo Motor 750W SGMJV		230 V
Yaskawa Servo motor SGMJV- @		A5A@		01A@	02A@	04A@	08A@
Rated output *1	W		50	100	200	400	750
Rated torque 1,2	N·m		0.159	0.318	0.637	1.27	2.39
Instantaneous peak torque*1	N·m		0.557	1.11	2.23	4.46	8.36
Rated current*1	A (rms)		0.61	0.84	1.6	2.7	4.7
Instantaneous max. current *1	A (rms)		2.1	2.9	5.8	9.3	16.9
Rated speed *1	min-1		3000
Max. speed *1	min-1		6000
Torque constant	N·m/A (rms)		0.285	0.413	0.435	0.512	0.544
Rotor moment of inertia (JM)	kg·m2x10-4 (without brake)		0.0414	0.0665	0.259	0.442	1.57
Rotor moment of inertia (JM)	kg·m2x10-4 (with brake)		0.0489	0.0740	0.323	0.506	1.74
Allowable load moment of inertia (JL)	Multiple of (JM)		15			10
Rated power rate*1	kW/s		6.11	15.2	15.7	36.5	36.3
Rated angular acceleration*1	rad/s2		38400	47800	24600	28800	15200
Encoder	Standard		Incremental encoder (20 bits)
Encoder	Option		Incremental encoder (13 bits)/ Absolute encoder (20 bits)
Allowable radial load	N		78		245		392
Allowable thrust load	N		54		74		147
Approx. mass	Kg (without brake)		0.3	0.4	0.9	1.3	2.7
Approx. mass	Kg (with brake)		0.6	0.7	1.5	1.9	3.6
