Yaskawa Servo Motors Break 850W SGM7G-09AFC6C

Yaskawa Servo Motors Break 850W SGM7G-09AFC6C
We are First Class Yaskawa servomotors dealer and Yaskawa servomotors distributor in China.
We can Supply Yaskawa electric automation parts,such as Yaskawa PLC,Yaskawa Servo Motor&Yaskawa servo drive,Yaskawa VFD,Yaskawa Robot and So on.
Support All seriesl Yaskawa ∑5 SGMGV Rotary Servomotor,Yaskawa ∑5 SGMJV Rotary Servomoto,Yaskawa ∑7 SGM7G Rotary Servomotor,Yaskawa ∑7 SGM7J Rotary Servomotor
100% Original and new,In stock by Yaskawa Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Yaskawa Servo Motors Break	200 V
Yaskawa Servo Motor SGM7G	03A	05A	09A	13A	20A	30A	44A	55A	75A	1AA	1EA
Time Rating	Continuous
Thermal Class	UL: F, CE: F
Insulation Resistance	500 VDC, 10 MΩ min.
Withstand Voltage	1,500 VAC for 1 minute
Excitation	Permanent magnet
Mounting	Flange-mounted
Drive Method	Direct drive
Rotation Direction	Counterclockwise (CCW) for forward reference when viewed from the load side
Vibration Class*1	V15
Surrounding Air Tem- perature	0°C to 40°C (60°C max.)*4
Surrounding Air Humidity	20% to 80% relative humidity (with no condensation)
Installation Site	• Must be indoors and free of corrosive and explosive gases.• Must be well-ventilated and free of dust and moisture. • Must facilitate inspection and cleaning. • Must have an altitude of 1,000 m or less. (With derating, usage is possible between 1,000 m and 2,000 m.)*5 • Must be free of strong magnetic fields.
Storage Environment	Store the Servomotor in the following environment if you store it with the power cable disconnected.Storage temperature: -20°C to 60°C (with no freezing) Storage humidity: 20% to 80% relative humidity (with no condensation)
Impact Acceleration Rate at Flange	490 m/s2
Number of Impacts	2 times
Vibration Resis-tance*3 Vibration Acceleration Rate at Flange	49 m/s2 (24.5 m/s2 front to back)							24.5 m/s2
SGD7S-	3R8A		7R6A	120A	180A	330A		470A	550A	590A	780A
SGD7W- SGD7C-	5R5A67R6A6		7R6A	–
